MFX Pedal:

• A large varied collection of 18 effects programs, all with numerous controllable parameters.
• Effect parameters freely assignable to panel knobs, expression input or MIDI control.
• Works well with guitar, line and ‘pro’ level instruments.
• Inbuilt optional analogue gain stage (+10dB) for low level signals.
• Global selectable True Bypass and buffered dsp bypass with foot switch control and LED indication.
• Stereo I/O paths with all Neutrik jacks.
• Clip level indication LED.
• Tap Tempo and triggering via foot switch.
• Din MIDI input for MIDI beat clock synchronisation, user, preset selection, remote bypass and MIDI CC control.
• All settings remain between power cycles.
• Factory and user saveable presets per effect.
• USB-C for quick and easy ‘drag and drop’ firmware updates via computer.
• Rugged lightweight black anodised aluminium enclosure.
• 2 Year Warranty.
• Made in England.

• Power: 9v DC power, center negative (not included)
• Current Draw: 100mA (200mA+ supply recommended)
• Input Impedance: 1MOhm
• Output Impedance: 1KOhm
• Max Input level: +8 dBu (2 Vrms ~ approx 5Vpp)
• Optional Gain Stage: +10 dB
• Bypass: True Relay & Buffered DSP based
• Dimensions: 125x65x70mm
• 16 Bit / 44.1kHz Stereo processing with 32 bit floating point DSP
• ARM CPU based DSP

Digi-PCM Echo

Feature rich digital delay taking inspiration from early prime time rack delay units with added modern features.

Tape-Tech Echo

Tape style delay with a digital pitch shifter bolted on.

Crumbular Echo

More experimental granular style echo.

Ursa Minor Echoverb

Emulation of the classic Ursa Major ‘Space station’ providing more delays and reverb type effects.

Pocket PL8 Reverb

Emulation of very early digital style reverbs with a dense metallic sound.

Almicon Reverb

Emulation of 80s studio style reverb great for bright rooms and vast synthetic spaces.

Quaidra Reverb

Emulation of a popular 90s rack reverb. Excels at creating airy, atmospheric reverbs.

Yetti Reverb

A more modern FDN based reverb engine. Added pitch shifter for other worldly effects.

Slinky Reverb

Loosely modelled spring type reverb with extra ‘Boing’.

TY-50 Dynamics

A multi mode dynamics processor featuring both classic compression and transient shaping modes.

TH-30 Distortion

A versatile distortion program with distortion types ranging from analog style saturation to intense digital wavefolding.

2051 Bit Corrupter

Real-time audio buffer designed to imitate malfunctioning digital audio equipment.

Modulating Panner

Clock-syncable mono or stereo auto-pan with an additional scan mode that cross fades between 2 input signals. Use for VCA, Panner, crossfader, tremolo type effects.

Ring + Freq Modulator

Pair of classic modulation effects in stereo, tailored towards otherworldly and dissonant sounds.

Ensembles Ensemble

Simulation of classic chorus and ensemble effects. An added digital pitch shifter takes the effect beyond traditional chorus circuits.

Multi Phaser

Great sounding multi stage Phaser with numerous editable parameters.

Squoval Resonator

8 band mono or 4 band true-stereo resonator built from a collection of linked resonant band pass filters.

Utilities

Simple oscilloscope, clock utility and a spectral analyser.
